T-Display P4

T-Display P4

Based on the ESP32-P4 platform, available in AMOLED (rear camera) and TFT punch-hole display (under-screen camera) versions.

Specifications

MCU1 ESP32-P4,RISC-V Dual-core 360Mhz + Single 40Mhz
Features

Powerfulimage and Voice processing

JPEG Codec,ISP, PPA, H264 Encoder, MIPI CSI, MIPI DSI
Flash 16MB
PSRAM 32MB
Platform ESP-IDF,VS code
GPS Module L76K

MCU2 Ā ESP32-C6
Features 2.4 GHz Wi-Fi6(802.11ax), Bluetooth 5(LE)
Onboard function Capacitive touch screen+TFT/AMOLED optional
l2S Speaker & Microphone & Motor+ RTC+ Ethernet
Expandablel/0 supports external Keyboard Board
LoRa Module SX1262
2MP MIPI Camera 0V2710/ 1080p@30 fps,720p@60 fps
Charge Management LGs4056H
I2C Battery Gauge BQ27220
12C GPl0 Expansion lC XL9535/ 24-pin CMOSIc 16-bit GPIO
9-AxiS MEMS IMU lCM20948/ MotionTracking + DMP
Size 63 x109x22mm
USB Charging 5V, 500mA

Tech Support

ā„¹ļøProduct information
Check out our GitHub repository for sample code and more detailed information about this board.

šŸ’»Technical support
Visit our GitHub community and post a description of the problem, and our engineers will help you directly.

What's In The Box

4.1 Inch AMOLED [H753] Version

4.05 Inch TFT [H753-01] Version

Select Version
Select Frequency (SX1262)
From $34.09

Original: $97.40

-65%
T-Display P4ā€”

$97.40

$34.09
