T-Echo Plus

T-Echo Plus

Key Feature Upgrades

  • ✅BHI260AP IMU — Improved motion sensing
  • ✅Vibration Motor — Tactile feedback
  • ✅2400mAh Battery — Extended usage
  • ✅Buzzer — Audible alerts

Structural Improvements

  1. 1/4-inch Mount Interface
  2. Climbing Finger Loop

Specification

MCU NRF52840
FLASH 2MB
RAM 2MB
Bus Interfaces UART, SPI, TWI, PDM, 12S, QSPI
Wireless Connectivity Bluetooth 5, Thread,
Bluetooth Mesh, ANT, 802.15.4, Zigbee
With/ Without BME280 temperature pressure sensor
SX1262 LoRa Transceiver Long Range, Low Power
Global frequency coverage 433, 868, 915Mhz
Battry Capacity 2400mAh

1.54-inch SPI E-Paper Display

Grey level 2
Resolution 200x200
 Full refresh time 2S

L76K Multi-System Positioning GNSS module

Support System GPS, GLONASS, BeiDou, QZSS

Tech Support



ℹ️Firmware

1. LILYGO

Check out GitHub repository for sample code and more detailed information about this board.

 💻LILYGO GitHub Community
Visit our GitHub community, post a description of the problem and our engineers will help you directly.

What's In The Box

Select Firmware
Select Frequency
Select Color
From $22.21

Original: $63.45

-65%
T-Echo Plus—

$63.45

$22.21
